Plastic PPS 1.6MPa 1MHz Ultrasonic Flow Transducer

Ask Lasest Price
Brand Name :	Yujie
Model Number :	HJ-SB1000-1709A
Certification :	ISO9001
Price :	Negotiable
Payment Terms :	T/T, Western Union
Supply Ability :	10000 Piece/Pieces per Month
Delivery Time :	3~30 working days

Add to Cart

Product Details
Company Profile

Plastic PPS 1.6MPa 1MHz Ultrasonic Flow Transducer

1MHz Ultrasonic Flow Transducer Plastic Housing Accurate Measurements With Small Size

Specifications:

Model	HJ-SB1000-1709A
Frequency(kHz)	1MHz±5%
Bandwidth	200kHz
General sensitivity 0 dB=3 Vp-p;Period:5；; Distance:7cm	>1.0v
Beam width(-3dB full angle)	9±2°
Static capacitance	520PF±20%
Min. parallel resistance	700Ω±30%
Max. driving Voltage(2% duty cycle tone burst)	＜200V
Operating temperature	0～50℃
Protection/waterproof level	IP68
Max. driving pressure	1.6MPa
Housing material	PPS
Wire length	65cm

FAQ:

Q: how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

Q: what can you buy from us?

Ultrasonic Transducer,Ultrasonic Equipment,Piezoelectric Ceramic,Ultrasonic Generator,ultrasonic equipment parts

Q: why should you buy from us not from other suppliers?

The company has more than ten years of experience in design and development, product variety, wide range of applications, large-scale production, rapid delivery, quality system improvement, process control is guaranteed.

Q: How soon can we get the detailed quotation?

Firstly please kindly tell us the size, material and demand quantity, your drawing with technical requirements is best.

If you only have samples, you can also send us.

We will quote our best price in 24 hours, for simple items, we will quote in 1 hour.

Q: what services can we provide?

Accepted Delivery Terms: FOB；

Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;

Accepted Payment Type: T/T;

Language Spoken:English,Chinese

All specification taken typical at 25℃

Product Tags:

PPS Ultrasonic Flow Transducer

1.6MPa Ultrasonic Flow Transducer

1MHz Ultrasonic Flow Sensor

Plastic PPS 1.6MPa 1MHz Ultrasonic Flow Transducer
