High Bandwidth 200KHz Ultrasonic Transducer Wide Operating Temperature

    Buy cheap High Bandwidth 200KHz Ultrasonic Transducer Wide Operating Temperature from wholesalers

    Buy cheap High Bandwidth 200KHz Ultrasonic Transducer Wide Operating Temperature from wholesalers
    • Buy cheap High Bandwidth 200KHz Ultrasonic Transducer Wide Operating Temperature from wholesalers

    High Bandwidth 200KHz Ultrasonic Transducer Wide Operating Temperature

    Ask Lasest Price
    Brand Name : Yujie
    Model Number : HJ-2112/1M
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 10000 Piece/Pieces per Month
    Delivery Time : 3~30 working days
    • Product Details
    • Company Profile

    High Bandwidth 200KHz Ultrasonic Transducer Wide Operating Temperature

    Ultrasonic Flow Meter Transducer With 1MHz Low Cost For Flow Meter

    Specifications:

    ModelHJ-2112/1M
    Frequency(kHz)1MHz±5%
    Bandwidth200kHz

    General sensitivity

    0 dB=3 Vp-p;CW; Distance:7cm

    -30dB min
    Beam width(-3dB full angle)6±2°
    Static capacitance1200PF±20%
    Min. parallel resistance250Ω±30%
    Max. driving Voltage(2% duty cycle tone burst)<300V
    Operating temperature-20~70℃
    Protection/waterproof levelIP68
    Max. driving pressure
    1.6MPa
    Housing material
    PPS
    Wire length
    65cm

    All specification taken typical at 25℃
